Appliance Kserver 4000

Network Appliance/Server

Features and Benefits

Features

  • Up to 64 GB DDR4 RAM
  • 4 x 10 Gbps SFP+ interfaces
  • 6 x 2.5 Gbps Ethernet interfaces
  • Redundant power supply (550 W)
  • Compatible with Windows, Linux, FreeBSD, and pfSense
  • PCIe 4.0 x8 slot for expansion
  • TPM 2.0 and support for RAID 0/1/5/10
  • Designed for continuous operation in high-traffic environments

Model

  • Processor: Intel® Core™ i7-12700
  • Memory: 1 x 16 GB DDR4 (expandable up to 64 GB)
  • Storage: 1 x 256 GB NVMe SSD + up to 4 SATA drives (2.5” or 3.5”)
  • Networking: 6 x Intel® I226-V (2.5 Gbe), 4 x Intel® X710-BM2 (10 Gbe – SFP+)
  • Ports: 2 x USB 3.1, 1 x Console RJ45, 1 x HDMI
  • Expansion: 1 x PCIe 4.0 x8, 1 x M.2 E-Key
  • Power supply: Redundant 550 W, input 100–240 VAC
  • Operating temperature: 0 ºC to +50 ºC
  • Compatibility: Windows, Linux (5.15+), FreeBSD, pfSense
  • Weight and dimensions: 10.15 kg / 8.9 x 43 x 52.5 cm (H x W x D)

Resources

Datasheet

KServer_4000
